Awọn eroja Ọja

Aṣeṣe No.: EV101WXM-N81

Apoti & Ifijiṣẹ

Ta sipo:

Piece/Pieces

Ifihan ọja

Ev101WXM-N81 jẹ module LCD 10.1-inch ni lilo imọ-ẹrọ A-Sift-LCD. O ti ni ipese pẹlu apẹẹrẹ afẹhinti, pẹlu di afẹyinti awakọ LED, ko si ifọwọkan. Ifihan ifihan jẹ 1280 (RGB) × 800 (WX 800 (ipin ipin), ipin abala jẹ 16:10 (Iwọn), ati awọn piksẹli ti jẹ idaya ni awọn ila inaro RGB. Iwọn agbegbe ifihan rẹ jẹ 216.96 × 135.6 (Iwọn wiwo ni 219.2 × 132) × 13.4 (sisanra (Ty.). Ni awọn ofin ti igbesoke, ọja yii nlo orisun ina ti kokoro kan pẹlu igbesi aye awọn wakati 50k, pẹlu awakọ mule. Ev101WXMWXM-N81 nlo awọn LVDS (1 ch, 8-bit) ni wiwo, lapapọ ti asopọ ebute, foliti iboju wa ni 3.2V (tẹ.). Oṣuwọn imukuro iyipo inaro pataki FV jẹ 60HZ. O ṣiṣẹ ni -20 ° C si 70 ° C ati awọn ile itaja ni -30 ° C si 80 ° C. Da lori iwaju LED funfun rẹ, igbesi aye naa ju awọn wakati 50,000 lọ.

R-Star ti ipilẹṣẹ lati Shenzhen, China, a jẹ olupese ọjọgbọn ti Ilana LCD to gaju, Ni ita gbangba ni ita gbangba Saami LCD, ile-iṣẹ saami saami ti TFT-LCD, Fireemu ifihan, LCD lẹẹmeji, ina-isalẹ-isalẹ-isalẹ-isalẹ-isalẹ-isalẹ-isalẹ-isalẹ ẹgbẹ-ala-nla miiran. Ni kukuru, igbega ni diẹ sii ju ọdun marun 5 ti Iriri Imọlẹ Itanna ti o ga julọ, ọdun 8 ti agbara iṣelọpọ, ọdun 10 ti o ga.

brand	BOE	Model name	EV101WXM-N81
size	10.1 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1280(RGB)×800, WXGA, 149PPI	Pixel configuration	RGB vertical bar
Display Area	216.96×135.6(H×V)mm	Surface treatment	/
Visual size	233.2×152.9×10.4(H×V×D) mm	Contrast Ratio	900:1 (Typ.) (TM)
Brightness(cd/m²)	500cd/m²(Typ.)or customized	Outline dimension	233.2×152.9×10.4(H×V×D)mm
Viewing Angle	85/85/85/85 (Typ.)(CR≥10)
Signal interface	LVDS (1 ch, 8-bit) ,erminal, 20 pins
work environment	Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C

Awoṣe iwọn kanna ati awọn aye ti wa ni atẹle

brand	BOE	Model name	EV101WUM-N20
size	10.1 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1920(RGB)×1200, WUXGA, 224PPI	Pixel configuration	RGB vertical bar
Display Area	216.806×135.504mm(H×V)	Surface treatment	/
Visual size	/	Contrast Ratio	900:1 (Typ.) (TM)
Brightness(cd/m²)	600cd/m²(Typ.)or customized	Outline dimension	229.45×149.22(H×V)mm
Viewing Angle	80/80/80/80(Typ.)(CR≥10)
Signal interface	LVDS (1 ch, 8-bit) ,erminal, 45 pins
work environment	Storage temperature: -25 to 80 °C Operation Temperature: -20 to 70 °C

brand	BOE	Model name	AT101WSM-N11-58P0
size	10.1 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1024(RGB)×600, WSVGA, 117PPI	Pixel configuration	RGB vertical bar
Display Area	222.72×125.28mm(H×V)	Surface treatment	Fog surface，Hard coating (3H)
Visual size	226×128.6(H×V)mm	Contrast Ratio	500:1 (Typ.) (TM)
Brightness(cd/m²)	500cd/m²(Typ.)or customized	Outline dimension	235×144.9×5.44mm(H×V×D)
Viewing Angle	80/80/60/70(Typ.)(CR≥10)
Signal interface	LVDS (1 ch, 6/8-bit) , 60 pins , FPC
work environment	Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C

brand	BOE	Model name	EV101WXM-N82
size	10.1 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1280(RGB)×800 [WXGA] 149PPI	Pixel configuration	RGB vertical bar
Display Area	216.96 × 135.6 mm (H×V)	Surface treatment	/
Visual size	/	Contrast Ratio	900:1 (Typ.) (TM)
Brightness(cd/m²)	500cd/m²(Typ.)or customized	Outline dimension	228.6 ×149.2×6 mm (H×V×D)
Viewing Angle	85/85/85/85(Typ.)(CR≥10)
Signal interface	LVDS (1 ch, 8-bit) ,erminal, 40 pins
work environment	Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C
