Aṣeṣe No.: LA123WF4-SR03
Iwọn otutu ti ṣiṣiṣẹ ti La123WF4-Sr03 ~ 85 ~ 85 ° C, ati iwọn otutu ibi-itọju jẹ -40 ~ 95 ° C. Ipinnu ifihan ti La 83WF4-Sr03 ni 1920 (RGB) × 720, ati ipin ẹya: giga), awọn piksẹli ti wa ni idaya ni awọn ila inaro RGB.
Iwọn agbegbe ti La 8kf4-Sr03 jẹ 292.032 × 109.012 (w × 162) ati iwọn hihan jẹ 396.5 × 118 (W) × 100 (h) × 100 (h) × 100 ( D) m, itọju dada jẹ titan lile.
Idiwọn ati isọdi lati pade awọn aini ayika.
RỌRỌ-Star Gbogbogbo-Star Fihan awọn panẹli ṣe afihan ipinnu giga-giga, hihan ita gbangba, ati igbesi aye ọja. Awọn ohun elo ọja bo awọn ẹrọ ti o ni alaifọwọyi (ATM), aaye ebute, awọn kọnputa alaye ti ile-iṣẹ, awọn ẹrọ iṣowo Awọn ifihan Marine duro de. A tun pese apẹrẹ apẹrẹ ti a ti ijọba ati ṣatunṣe awọn solusan ifọwọkan lati ṣe iranlọwọ awọn alabara dagbasoke awọn apoti ebute ti ifigagbaga.
| brand | LG Display (LG Display) | Model name | LA123WF4-SR03 |
| size | 12.3 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution | 1920(RGB)×720 167PPI | Pixel configuration | RGB vertical bar |
| Display size | 292.032×109.512(H×V)mm | Surface treatment | Hard coating |
| Brightness(cd/m²) | 600 cd/m² (Min.) or customized | contrast | 800:1 (Min.) (TM) |
| Viewing Angle | 89/89/89/89 (Min.)(CR≥10) | Appearance of size | 310×128×10.75mm(H×V×D) |
| Signal system | RSDS (2 Channel) , 110 pins , FPC | ||
| Maximum rated | Storage temperature: -40 ~ 95 °C Working temperature: -40 ~ 85 °C Vibration resistance: 3.0g (29.4m /s²) |
