LQ150x1lw96

Min. Bere fun:1 Piece/Pieces

Awọn eroja Ọja
Apoti & Ifijiṣẹ
Other information

Awọn eroja Ọja

Aṣeṣe No.: LQ150X1LW96

Apoti & Ifijiṣẹ

Ta sipo:

Piece/Pieces

Ifihan ọja

Afihan ifihan Lq1506 jẹ 1024 (RGB) × 768 (Xga), ipin ẹya jẹ 4: 3 (iwọn), ati awọn piksẹli ti jẹ idaya ni awọn ila inaro RGB. Iwọn agbegbe Ifihan ti LQ150x1lw96 jẹ 304,128 × 228.5 (W) × 253.5 (h) × 10.1 (h) mm. Matte Pari, ti a fi lile (3h), iwuwo apapọ 950g (Max.)

Apoti oju-ẹhin si eti ina ina-Iru iwọn otutu rẹ jẹ -2 ~ 70 ~ 70 ~ 70 ° C, eyiti o dara fun ile-iṣẹ ati aworan iṣoogun.

brand	Sharp	Model name	LQ150X1LW96
size	15inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1024(RGB)×768 [XGA] 85PPI	Pixel configuration	RGB vertical bar
Display Area	304.128×228.096mm(H×V)	Surface treatment	Fog surface，Hard coating (3H)
Visual size	307.2×231.1mm(H×V)	Contrast Ratio	1500:1 (Typ.) (TM)
Brightness(cd/m²)	500cd/m²(Typ.)or customized	Outline dimension	326.5×253.5×10.1(H×V×D)mm
Viewing Angle	85/85/85/85 (Typ.)(CR≥10)	work environment	Storage temperature: -25 to 70 °C Operation Temperature: -20 to 70 °C
Signal interface	LVDS (1 ch, 6/8-bit),erminal,20 pins
supply voltage	3.3V (Typ.)
