22 inch ita gbangba ti o ga julọ ti o ga julọ

Min. Bere fun:1 Piece/Pieces

Awọn eroja Ọja
Ipese Agbara & Awọn ifitonileti Afikun
Apoti & Ifijiṣẹ
Other information

Awọn eroja Ọja

Brand: Rìrindlcd

Ipese Agbara & Awọn ifitonileti Afikun

Ise sise: 160K

Ibi ti Oti: Shen Zhen

Ijẹrisi: CE/ROSH/UL/ISO9001

Apoti & Ifijiṣẹ

Ta sipo:

Piece/Pieces

Ifihan ọja

Panel Brand	RISINGSTAR	Panel Model	RS220WPM-NE10
Panel Size	22.0"	Panel Type	a-Si TFT-LCD , LCM
Resolution	1680(RGB)×1050, WSXGA+, 90PPI	Pixel Format	RGB Vertical Stripe
Display Area	473.76(W)×296.1(H) mm	Bezel Opening	477.7(W)×300.1(H) mm
Outline Size	493.7(W)×320.1(H) ×10.7(D) mm	Surface	Antiglare (Haze 25%), Hard coating(3H)
Brightness	1000nit or customized	Contrast Ratio	1000:1 (Typ.) (TM)
Viewing Angle	85/85/80/80 (Typ.)(CR≥10)	Display Mode	TN, Normally White, Transmissive
Display Colors	16.7M 72% NTSC	Response Time	1.5/3.5 (Typ.)(Tr/Td)
Frequency	60Hz	Lamp Type	3 strings WLED , 40K hours , Without Driver
Weight	1.83Kgs (Typ.)	Input Voltage	5.0V (Typ.)
Signal Interface	LVDS (2 ch, 8-bit) , 30 pins Connector
Environment	Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -25 ~ 60 °C

Rs220WM-Ne10 jẹ ifihan LCD ti oorun 22 ti a ṣe afiwe ifihan LVD. O le wa ni ṣiṣe ni awọn iwọn otutu lati -20 ~ 70 ℃ ati awọn iwọn otutu ipamọ wa lati -30 ~ 80 ℃. Rs220WPM-Ne10 jẹ 1000 nits module TFD ti o gaju module. O dara fun awọn ẹrọ ile-iṣẹ, awọn ẹrọ ọwọ, ẹrọ iṣoogun, ita gbangba ati agbegbe ologbele-ita.

Awọn ẹya

1. Imọlẹ giga, ifiwera giga, akoko idahun esi ti o yara, atilẹyin awọ-ọpọlọpọ, igun wiwo jakejado; igun wiwo pupọ;

2. Laini Iṣeduro Iṣeduro Ọjọgbọn Orilẹ-ede, awọn miliọnu agbegbe eruku-eruku, ara iboju ati ipo iboju ipo;

3. Eriri, FCC, FCC, CCC, CCC, Ul, roshs;

4. Imọ-ẹrọ Ẹlẹda ọjọgbọn.

5. Itẹmọra surdy, ikolu ti ita, kamas irin.
