33.8 "BEE RV338FBM-N00 ile iṣelọpọ ile-iṣẹ

Min. Bere fun:1 Piece/Pieces

Awọn eroja Ọja
Apoti & Ifijiṣẹ
Other information

Awọn eroja Ọja

Aṣeṣe No.: RV338FBM-N00

Apoti & Ifijiṣẹ

Ta sipo:

Piece/Pieces

Ifihan ọja

RV338FBM-N00, module LCD LCD kan pẹlu imọ-ẹrọ A-LCD. Awọn ẹya aṣoju ti module yii: Imọlẹ giga, Titẹ-ọrọ funfun, pẹlu awakọ ti mu, iboju olufe ultra. Iwọn otutu ti iṣiṣẹ ti module jẹ -20 ~ 70 ° C, iwọn otutu ibi ipamọ jẹ -30 jẹ 1.5g (14.7 m / s²). Awọn sakani jakejado pupọ, o dara fun ile-iṣẹ, aami oni-nọmba, ifojusi ita gbangba.

O ga aṣayan RV338FBM-N00 Ifihan Afihan (RGB) × 720, ipin abala jẹ> 3: 1 (iwọn), ati awọn piksẹli ti jẹ idaya ni awọn ila inaro RGB. Iwọn agbegbe ifihan rẹ jẹ 825.6 × 232.2 (w wi 8 Fun 826.2 (w wi 86.2) ati iwọn hihan jẹ 863.6 (H) × 26.6 (D). Apapọ iwuwo 4.40 ± 0.5kgs.

[Itọsọna ala-ilẹ ati Ifihan inaro]

Ko dabi awọn panẹli ohun elo TV deede, o le jẹ awọn aworan daradara ni ipo ala-ilẹ tabi ipo ifihan inaro.

O le ṣiṣẹ ni iduroṣinṣin ni ọpọlọpọ awọn agbegbe ile-iṣẹ gẹgẹ bi soobu, gbigbe ọkọ irin ajo, ibojuwo aabo, ati awọn ile-iṣẹ iṣakoso wiwo, ati awọn ile-iṣẹ iṣakoso afiri ti awọn alabara.

lcd screen panel

Q: Bawo ni MO ṣe le wa ọja ti o tọ?

A: Jọwọ firanṣẹ awọn ibeere rẹ, a yoo ṣeduro awọn ọja aabo wa, ti ko ba baamu, a yoo ṣe atunṣe to ṣe pataki & isọdi pataki.

Q: Bawo ni atilẹyin ọja?

A: ayafi bibajẹ ti o fa nipasẹ awọn nkan eniyan, ọdun kan fun ọjọ ifijiṣẹ. Awọn ayidayida pataki yoo wa ni iwifunni.

high brightness LCD

brand	BOE	Model name	RV338FBM-N00
size	33.8 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	2560(RGB)×720, 78PPI	Pixel configuration	RGB vertical bar
Display Area	825.6×232.2mm	Surface treatment	/
Visual size	829.6×236.2mm(H×V)	Contrast Ratio	1200:1 (Typ.) (TM)
Brightness(cd/m²)	700cd/m²(Typ.)or customized	Outline dimension	863.6×267.6×27.6mm(H×V×D)
Viewing Angle	89/89/89/89 (Typ.)(CR≥10)	Backlight type	WLED, 40K hours, no drive
Signal interface	LVDS (2 ch, 8-bit) , 51 pins ,erminal
work environment	Storage temperature: -20 to 70 °C Operation Temperature: -30 to 80 °C

Awọn afi Gbona: 33.8 "BEE RV338FBM-N00 ile-iṣẹ, owo, ti a kọ nọmba, ti a ti kọju, 55 Inch LCD ifihan ifihan , Iṣafihan Windows , Akojọ LCD Speni, module LCD, ifihan didan giga.
